RAPIDv3 Extension

Raspberry Pi Interface Board

The Raspberry Pi Interface board rapid_v3_14u can be directly attached to the Raspberry Pi pin header. Two different assembly options are available:

  • for radar modules with 5 V power supply
  • for radar modules with 3.3 V power supply

The radar module can be enabled by a hardware jumper or a Raspberry Pi GPIO. An additional I2C based current, voltage and power monitor is additionally available which is helpful for exploring low power applications.

More details about this PCB in combination with a Raspberry Pi backend software is available at the Evaluation Kit page.
