Livedemo IoT

IoT Livedemo online

03.03.2022 |  Created by B. Göttel Livedemo

Our IoT sensor measures every 15min the water level of a small lake.

Read more
Silicon Radar Solution Partner

Solution Partner of Silicon Radar

08.02.2022 |  Created by B. Göttel Customization

We are now official solution partner of the Silicon Radar GmbH

Read more
Heart and breath detection of cats

Healthtracking for cats

08.12.2021 |  Created by T. Latzko Feasibility

We had a success in a consistent measurement of the breath and hearthbeat of various cats.

Read more
Comissioning RAGES system

Commisioning of a RAGES 5.8 GHz system

29.11.2021 |  Created by B. Göttel Development

Four 5.8 GHz RAGES system were installed and succesfully comissioned.

Read more
Livedemo Rapview

Livedemo Rapview online

08.11.2021 |  Created by B. Göttel Livedemo

Rapview is our web based GUI for interfacing with our RAPIDv3 modules.

Read more
New webpage layout

New webpage online

26.10.2021 |  Created by B. Göttel Company

Our webpage is completely new structured and optimized

Read more
Drone with 60 GHz radar module

The radar drone modification

09.09.2021 |  Created by T. Latzko Feasibility

The low power 60GHz frontend allowed to measuere crop height, trees and the complete profile of a powercable using a mavic mini drone.

Read more
Foam measurements

Levelsensing in hot and challenging environments

03.05.2021 |  Created by T. Latzko Feasibility

With an advanced static background estimator it is possible to measure in extreme environments with a high accuracy down to the mm level.

Read more
Third-Party Network (TI)

Third Party Network Texas Instruments

27.10.2020 |  Created by B. Göttel Customization

Using and offering the fully integrated transceivers of Texas Instruments we are now officially listed on their Third-Party Network

Read more
AGV including radar module

Collision avoidance for AGV

23.09.2020 |  Created by T. Latzko Feasibility

A dynamic background estimator is used for implementing a collision avoidance for automated guided vehicle.

Read more
Filled pipe measurements

Dirt in a pipe

03.08.2020 |  Created by T. Latzko Feasibility

It is possible to measure into small pipe. Either water flow or dirt can be detected. The precise filllevel of the pipe is the result. The diameter…

Read more
Comissioning RAGES system

Commisioning of a RAGES system

29.07.2020 |  Created by B. Göttel Development

Two 24 GHz RAGES system were installed and succesfully comissioned.

Read more

Foam measurement

22.07.2020

For a radar measure the thickness of foam is not an easy task. With the right frequency choise for the targeted foam it was possible to measure the…

Read more
IBC tank measurements

IoT on top of an IBC

01.06.2020 |  Created by T. Latzko Feasibility

IBC are wide spreaded tanks for a variaty of fluids. The first fieldtest with the IoT sensor was succesfull.

Read more
Accuracy enhancement by 8

Commisioning: Robotic accuracy enhancement

18.02.2020 |  Created by B. Göttel Development

Four 122 GHz radar sensors are used for measuring the exact position within a defined working plane of a 6-axis industrial robot

Read more
Award participants 2019

Award Winner

11.11.2019 |  Created by B. Göttel Company

We are proud winners of the Innoviationspreis des Landes Baden-Württembergs.

Read more
Level measurements

Level measurements

10.08.2019 |  Created by B. Göttel Feasibility

Measuring solutions for surface water, rivers, open channels and groundwater.

Read more
RAPIDsense

Robotic accuracy enhancement

10.07.2019 |  Created by B. Göttel Development

Four 122 GHz radar sensors are used for measuring the exact position within a defined working plane of a 6-axis industrial robot

Read more
Thickness measurements of dielectrics

Thickness measurements of dielectrics

10.04.2018 |  Created by T. Latzko Feasibility

Dielectric thickness measurements are performed.

Read more
